SLK 5 SKII

Approvals

Technical data
Box type
325 x 180 x 280 mm
Nominal voltage
300 V
Nominal current
24 A
Max. ambient temperature
T85
Wire skinning length
9 + 1 mm
Clamping range
Upper
0.5 - 2.5 mm²
Lower
0.5 - 2.5 mm² solid
1.5 - 2.5 mm² rigid
Art.Nr. Material description Length Width Height
88167916 SLK 5/5 SKII 1-2-3-4-5 35.0 mm 27.0 mm 24.0 mm
88167912 SLK 5/5OF SKII 1-2-3-4-5 45.4 mm 27.0 mm 19.0 mm
Datasheet_SLK_5_SKII
pdf
684 KB
