KADO 2/3 OS
Cable connection boxes with opened screws
All benefits at one glance
- Screwless strain relief
- Lower product design
- Time-saving cable assembly due to opened screws
- Suitable for RAST 5 connectors
- New robust hinge mechanism
- Clearly arranged pole engravings inside
- Same cutout as KADO 1/3 IMP and KA 1/1 IMP, KA 1/3
- Easier earth Connection
- Complies with requirements to EN 60335-1
- Glow wire test for GWT 750ºC / GWIT
- Fast and save contacting
- Optional: external earthing
KADO 2/3 - Our "Bestseller"
For single phase applications.
Technical data
Box type
Nominal voltage
Nominal current
Max. ambient temperature
Wire stripping length
Clamping range
Models
88167794
KADO 2/3 OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88167795
KADO 2/3 2,5 OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88167796
KADO 2/3 2,5 EE OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88168143
KADO 2/3 2,5 OZ OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88167798
KADO 2/3 R5 OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88167895
KADO 2/3 OZ OS
61mm 2.4in
38mm 1.5in
43mm 1.69in
88167797
KADO 2/3 EE OS
61mm 2.4in
49mm 1.93in
43mm 1.69in
